Magic Plan App: Floor Plans Without Measuring Tapes (aka The Coolest Thing Your Phone Can Do)

DIY diva

I’m trying really hard right now to write this posts without using excessive exclamation points. It’s a struggle because one of my coworkers recently sent me what I’m pretty sure is the coolest app ever invented!!!

Sorry, I couldn’t help myself. But this is actually pretty sweet, and nobody paid me, emailed me, strung me up by my toes and made me listen to pop music, or otherwise tortured or coerced me into to saying this.

The app is called Magic Plan, and it’s appropriately named, because as anyone who has ever spent 15 hours with a tape measure and some graph paper trying to get an accurate floor plan of their house will tell you, to be able to accomplish this is 15 minutes is pretty freaking magical…

Untitled

That’s the first floor of the Liberty House, by the way. And I created this floor plan on my phone (which is also downloadable as a PDF, JPEG, DXF, or available on the web) by standing in the center of each room and taking pictures of it.

For real, people.

I don’t know how the magic of it works (I mean I have some thoeries that don’t involve magic pixies) but frankly I don’t care. You just stand in the middle of a room and virtually “mark” the corners, then assemble the rooms for an entire floor…

Untitled

If things are a little “off” the app understands and adjusts doorways to fit, etc. And you can go into any room after the fact and quickly adjust the sizes if something isn’t right, plus add windows, closets, stairs, etc.

Untitled

You can also snap a picture of each room for reference.

Would I build a house from these plans? Well, this is me, so yes, but obviously it’s not totally foolproof. As you can see above I need to do a little adjusting for some thick walls and ductwork. But just to have as a reference on my phone for figuring out things like if I have room for a piece of furniture, or how much flooring I need, this is invaluable. Because before Magic Plan, this is how I kept track of  room measurements on my phone…

Untitled

Right? That’s not a joke. That’s seriously what I’ve been using as a reference for the last two months. So you can see where the compulsion to end every sentence with a lot of excitement is coming from!!!!!!

There are video tutorials built into the app (which runs on iPhones and iPads with a camera), but here’s a little sample of how it works.

Seriously, I haven’t been this pumped about my phone since I dropped it from a first-floor ceiling joist all the way down to the basement floor without it breaking. AND, the app and downloading a watermarked JPEG or PDF is completely free. For a non-watermarked version or other file types it’s only $2.49 per plan, which again, totally worth it. S0, all I’m saying is, probably you need this. I sure did.
